To modify this the Target parameter should be modified. On the menu that appears the user should select the Properties menu item. The user can then create a shortcut to the Surve圓2 program by right clicking on surve圓2.exe, and then clicking on Create Shortcut.
Find the Surve圓2.EXE program in the HYPACK folder on your computer.
Hypack max windows#
This is done in either Windows Explorer or by selecting the drive through My Computer. If LOG Backup time is used, Long Filenames should be selected in the Project Information menu of the Survey program as shown below. This keeps files much smaller, and in the case of loss of power, computer crash, etc., only 15 minutes of data would be lost, rather than a whole day's worth. Survey will close a datafile and open a new file every 15 minutes. You will notice I set the LOG Backup Time to 15.
Hypack max software#
This configures the software to close the datafile after the predetermined period and start a new datafile. This should be set to an interval consistent with the project requirements. This is also set in the Navigation Parameters. The Navigation Parameters are shown below.Īnother parameter that should be set is the Log Backup Time. The program will continue to restart the logging function as long as the GPS is within the start line gate distance. Once this is set the user cannot exit Survey without resetting this to zero because the Survey program will not allow the user to exit without stopping logging. To set the Start line gate the user must enter the Survey program and modify the Navigation Parameters. This will allow the program to automatically start logging when the program is started. In this case, the line length is only 20 meters. In order to log automatically upon entering Survey, the Start Line Gate should be greater than the line length. Survey's Start Line Gate must be set to a value greater than the distance from the antenna to the line file. The GPS antenna was situated around the centerpoint of the line file as shown below. In this demonstration, I created a single planned line 20 meters long. For a stationary GPS, you should create this line as short as possible and as close to the GPS antenna position as possible. All you really need is a single short line to automatically log data upon entering Survey. The project must have a Planned Line file.
The Geodetic Parameters and Hardware must be configured as you would in any Hypack project. In this demonstration, I named the project Hong Kong. The first requirement is that the user has configured a project with the parameters and names for that project.
Hypack max Pc#
Because of the risk of loss of power, this procedure necessitated the startup and logging of data within the Survey program as soon as the PC was booted up. It was originally devised for a customer who wanted to set up three RTK-GPS receivers on a building to monitor movement during an earthquake. This is to recover from a loss of power and start logging data as soon as the computer is restarted. This procedure is intended to allow a user to configure a project in the HYPACK MAX software and then start recording position data automatically without any user intervention. ID.Q6-15 Q. サーベイプログラムの自動処理(Procedure for Automatically Starting the Survey Program) A.
